1.2 Importance of the Manual for Assembly and Setup

This manual is essential for correctly assembling and setting up your B6.3 Team Kit. It provides step-by-step instructions, highlighting new features like the wide-pivot rear end and servo mount. The guide ensures proper configuration of components, preventing issues during assembly. By following the manual, users can optimize performance, avoid common pitfalls, and maintain the kit’s durability. It serves as a critical resource for achieving peak racing efficiency and reliability.

Specifications of the B6.3 Team Kit

The B6.3 Team Kit features a lightweight, durable design with a wide-pivot rear end, aluminum servo mount, and high-performance components like gear differentials and carbon fiber parts.

2.1 Chassis Configurations and Design

The RC10B6.3 features two chassis configurations, continuing the B6 platform’s legacy. It includes a wide-pivot rear end for improved traction and a chassis-mounted servo for direct steering. The 3mm extended chassis enhances stability, while updated side rails and top plate designs promote durability and precise handling. These configurations ensure optimal performance across various track conditions.

2.2 Key Components and Features

The B6.3 Team Kit includes a wide-pivot rear end for improved traction and a chassis-mounted servo for direct steering. Key components feature molded tower covers, wire clips, and an Octalock spur gear with LCF pads for consistent performance. Symmetric rear arms, aluminum ballstud mounts, and 5mm clamping wheel hexes enhance durability. These components work together to provide a balanced and responsive racing experience.

New Features Introduced in the B6.3

The B6.3 introduces a wide-pivot rear end and chassis-mounted servo for enhanced stability and direct steering. Molded tower covers and wire clips improve organization and durability, while the Octalock spur gear and LCF pads ensure consistent performance. These innovations refine the platform, offering improved traction and easier assembly for racers.

3.1 Wide Pivot Rear End and Servo Mount

The B6.3 features a new wide-pivot rear end with aluminum arm mounts, designed for use with 73mm arms and 69mm CVA bones. This enhances rear traction and provides a more predictable rear-end feel. The servo mount is now chassis-mounted, offering easier assembly and improved durability. An integrated transponder mount adds convenience, making the B6.3 more racer-friendly and efficient on the track.

3.2 Molded Tower Covers and Wire Clips

The B6.3 introduces molded front and rear tower covers, designed to protect the carbon fiber edges from damage and prevent track surface abrasion. These covers provide a smooth, even surface and keep mounting screws free from dirt buildup. Additionally, the kit includes molded wire clips for organizing motor and ESC wires, ensuring a clean and tidy setup. These features enhance durability and maintenance efficiency.

Assembly and Setup Guide

This section provides a detailed, step-by-step guide for assembling and setting up your B6.3 Team Kit. From unboxing to final adjustments, it covers essential tools, configuration tips, and expert advice to ensure a smooth and successful build. Follow these instructions carefully to optimize performance and prepare your kit for competition.

4.1 Required Tools and Accessories

To successfully assemble and set up your B6.3 Team Kit, ensure you have the following tools and accessories: a two-channel radio system, AA batteries for the transmitter, an Electronic Speed Control (ESC), and a screwdriver set. Additional tools like pliers, a hex key set, and a hobby knife are recommended for precise adjustments. These items are essential for completing the build efficiently and achieving optimal performance.

4.2 Step-by-Step Assembly Instructions

Begin by carefully unpacking and organizing all components. Start with the chassis assembly, ensuring proper alignment and secure fastening of parts. Install the servo mount and wide-pivot rear end, following the manual’s sequence. Proceed with the transmission and differential systems, then move to suspension and steering components. Apply shock oil to O-rings for smooth operation. Refer to the included diagrams and instructions for precise assembly steps. Ensure all bolts are tightened firmly and double-check for any missing parts or misalignments before finalizing the build.

Comparison Between B6.3 and B6.4

The B6.3 and B6.4 share similar platforms but differ in design refinements. The B6.4 introduces updated features like finer hole spacing in shock towers and enhanced durability in wing mounts, while the B6.3 focuses on foundational improvements such as the wide-pivot rear end and molded tower covers for better performance and ease of assembly.

5.1 Design and Performance Differences

The B6.3 and B6.4 differ in design and performance enhancements. The B6.3 features a wide-pivot rear end and chassis-mounted servo for improved stability and control, while the B6.4 introduces updated carbon fiber shock towers with finer hole spacing for precise adjustments. Performance-wise, the B6.4 offers enhanced durability in wing mounts and rear hub assemblies, while the B6.3 focuses on foundational improvements like molded tower covers and wire clips for ease of assembly and maintenance.

5.2 Upgrade Options and Compatibility

The B6;3 and B6.4 share compatibility with many Factory Team parts, allowing seamless upgrades. Key enhancements include FT Carbon Fiber Composite components and updated ball bearings for improved efficiency. Both models support interchangeable shocks, springs, and anti-roll bars, ensuring flexibility. Official documentation provides detailed compatibility charts, enabling users to upgrade confidently while maintaining optimal performance across both platforms.

Legacy Features Carried Over

The B6.3 retains proven features like the 3-gear Laydown Stealth® transmission and fluid-filled gear differential, ensuring consistent performance on high-grip surfaces while maintaining reliability and durability.

6.1 Transmission and Differential Systems

The B6.3 inherits the reliable 3-gear Laydown Stealth^® transmission, optimized for high-grip surfaces, and the fluid-filled gear differential, designed to withstand high load cornering. These systems ensure enhanced stability and consistent power delivery, maintaining the legacy of durability and performance. The gear differential now includes height adjustment inserts for precise driveshaft alignment, while the B6.3D features a ball differential for added versatility and tuning options.

6.2 Suspension and Steering Components

The B6.3 retains the V2 12mm Big Bore shocks with X-rings for low-friction operation and machined pistons for smoother action. The aluminum rear ballstud mount offers three link positions for adjustability. The direct-to-chassis servo mount enhances steering precision, while the updated steering bellcrank brace improves durability. These components ensure a responsive and consistent handling experience, maintaining the B6 legacy of reliability and performance.

Troubleshooting Common Issues

The B6.3 manual addresses common issues like shock oil viscosity, worn suspension parts, and improper gear mesh. It also covers electrical wiring problems for optimal performance.

7.1 Shock and Chassis Setup Problems

Common issues include improper shock oil viscosity, leading to inconsistent damping, and over-tightened shocks causing reduced suspension travel. Chassis problems may arise from uneven weight distribution or loose components. Ensure proper torque specs and verify o-ring lubrication. Consult the setup sheet for optimal configurations and refer to troubleshooting guides for resolving these issues effectively. Regular maintenance and correct assembly are key to avoiding performance hindering problems. Use green slime on o-rings for better sealing and reduced wear.

7.2 Gear and Transmission Maintenance

Regularly inspect gears for wear and damage. Lubricate the transmission with Motorcraft Dual Clutch Transmission Fluid. Ensure proper mesh between pinion and spur gears. Clean and inspect the Octalock spur gear and LCF pads for debris. Replace worn or damaged components promptly to maintain smooth operation. Avoid over-tightening, as this can lead to premature wear. Always consult the manual for specific torque specs and lubrication recommendations to ensure optimal performance and longevity.

Customer Service and Support

For assistance, contact Customer Service at Tel: 949.544.7500 or Fax: 949.544.7501. Our team is ready to help with inquiries, ensuring your B6.3 experience is seamless and satisfactory.
