prodigy p2 user manual

2.2 Wiring Instructions

Wiring the Prodigy P2 brake control requires careful attention to ensure proper functionality. Begin by connecting the black power wire to the vehicle’s battery, using a 20-amp circuit breaker to protect against electrical surges. The white ground wire should be securely attached to a clean, bare metal surface on the vehicle’s chassis. Connect the blue brake output wire to the trailer connector’s brake circuit, ensuring it is compatible with your trailer’s wiring system. The red stoplight switch wire should be linked to the vehicle’s stoplight circuit, activating the trailer brakes when the vehicle’s brakes are applied. Use the provided pigtail harness for a straightforward connection to the vehicle’s wiring system. Avoid any modifications to the harness, as this could void the warranty or cause malfunctions. For additional safety, double-check all connections to prevent voltage drops or short circuits. Proper wiring ensures reliable communication between the Prodigy P2 and the trailer brakes, guaranteeing smooth and proportional braking performance. Refer to the wiring diagram in the manual for precise instructions and verify all connections before testing the system.

Operation Overview

The Prodigy P2 operates using internal sensors to detect deceleration, delivering proportional braking for smooth trailer control. It features manual override, boost settings for customized braking, and a hold function for stationary situations, ensuring reliable performance in various towing conditions.

3.1 Understanding Proportional Braking

The Prodigy P2 employs proportional braking technology, which ensures that the trailer’s brakes engage smoothly and in sync with the towing vehicle. This system uses an internal sensor to detect deceleration, generating a braking signal proportional to the vehicle’s deceleration rate. This means the harder the vehicle brakes, the greater the braking force applied to the trailer, mimicking the driver’s braking style for seamless control.

Proportional braking is particularly advantageous as it reduces wear on both the vehicle and trailer brakes while enhancing safety. It also minimizes the risk of trailer sway by ensuring consistent and balanced braking. The P2’s advanced sensor technology allows for precise adjustments, enabling users to customize the braking response based on the trailer’s weight, road conditions, or personal preference.

Additionally, the Prodigy P2 features a boost function, which can amplify the initial braking force for trailers with heavier loads or less efficient brakes. This adaptability makes the P2 suitable for a wide range of towing applications, from small trailers to larger RVs. By providing proportional braking, the P2 ensures a smoother and more controlled towing experience, boosting driver confidence and safety on the road;

Features and Settings

The Prodigy P2 offers advanced features like proportional braking, manual override, and adjustable boost settings. It supports 2 to 8 brake applications, ensuring compatibility with various trailer configurations. Users can customize settings to suit their towing needs, enhancing control and safety.

4.1 Adjusting Boost Settings

Adjusting the boost settings on your Prodigy P2 brake controller is crucial for optimizing braking performance based on your towing needs. The boost feature allows you to apply additional braking power to the trailer brakes during stops, enhancing control and safety. To adjust the boost settings, follow these steps:

1. Locate the boost adjustment controls on the Prodigy P2 interface.
2. Use the buttons or dial to increase or decrease the boost level.
3. Test the braking performance with the new boost setting to ensure it meets your requirements.
4. Repeat the process until you find the optimal setting for your trailer and load.

Higher boost levels provide more aggressive braking, ideal for heavier loads, while lower levels offer smoother stops for lighter trailers. Proper adjustment ensures balanced and effective braking, preventing issues like trailer skidding or inadequate stopping power. Always refer to the user manual for specific guidance on adjusting boost settings for your Prodigy P2.

Troubleshooting Common Issues

Troubleshooting the Prodigy P2 brake controller can help resolve common issues efficiently. If the display does not turn on, check the power connection and ensure the battery is charged. A blown fuse or incorrect wiring may also cause this problem. For inconsistent braking performance, verify that the boost settings are properly adjusted and that the trailer brakes are calibrated correctly.

• If the controller shows an error light, it may indicate a short circuit or open circuit in the trailer wiring. Inspect the connections and repair any damage.
• If the brakes lock up unexpectedly, check for excessive boost settings or improper calibration of the proportional braking system.
• If the unit overheats, ensure proper ventilation and avoid mounting it near heat sources.

For persistent issues, consult the user manual or contact Tekonsha’s technical support. Regular maintenance and proper installation are key to avoiding most problems. Always ensure safety by addressing issues promptly to maintain reliable braking performance.

Safety Precautions

Ensuring safe operation of the Prodigy P2 brake controller is critical to prevent accidents and maintain reliable trailer braking performance. Always follow the manufacturer’s guidelines and take necessary precautions during installation and use.

• Avoid installing the Prodigy P2 near heat sources, as this may cause overheating and malfunction.
• Never connect the brake controller to electric-hydraulic brake systems, as it is not designed for such applications.
• Ensure the unit is mounted securely within the 0 to 360-degree range in the direction of travel to maintain proper functionality.
• Keep the brake controller away from moisture and extreme temperatures to prevent damage.
• Do not modify the wiring or circuitry without professional assistance, as this can lead to unsafe conditions.

Always test the braking system after installation to ensure proper operation. If you notice any unusual behavior or error indicators, address the issue immediately. For detailed safety guidelines, refer to the official Prodigy P2 user manual. Prioritizing safety ensures a secure and reliable towing experience.
